Vibrating feeder for cement production

(22) 04.04.2023

(43) 29.11.2023

(57) The disclosure discloses a vibrating feeder for cement production, which relates to the
technical field of cement production, and includes a feeding box. The feeding box is
provided with a feeding tank, a regulating mechanism is provided at the lower end of
the feeding box, a storage box is provided at one side of the feeding tank, and a
sweeping mechanism is provided at the other side of the feeding tank; a power
mechanism is provided at the position corresponding to the sweeping mechanism at
the front end of the feeding box. The disclosure provides a dust removal assembly,
when the feeding tank in the feeding box is feeding, the fan is turned on. The fan
creates a negative pressure in the fixed bucket through the connecting pipe, and the
dust generated by the feed enters the fixed bucket. The fan sends the dust into the
water tank of the dust removal box through the dust delivery pipe. The water in the
water tank performs preliminary treatment of the dust, and then the dust passes
through the partition board, after filtering through the dinas layer and the activated
carbon layer, and is discharged out of the dust removal box through the exhaust port.
The dust generated by the feed can be dealed with by setting the dust removal
assembly to reduce environmental pollution and physical damage to workers.

(71) Wuwei Leida Cement Co Ltd, (CN)
