Vertical mill feeding structure for cement production
(22) 14.04.2023
(43) 28.07.2023
(57) The utility model discloses a vertical mill feeding structure for cement production, which relates to the technical field of vertical mill feeding and comprises a temporary storage bin, a guide plate is connected in the temporary storage bin, a heating channel is arranged in the guide plate, a fan is mounted on the surface of the temporary storage bin, an air outlet end of the fan is connected with a heater, and an air inlet channel is connected below the heater. The air inlet end of the fan is connected with an air return channel. Through the arrangement of the material guide plate, the air inlet channel, the temperature sensor, the air return channel and the heating channel, the draught fan is matched with the heater to generate hot air flow, the hot air flow enters the heating channel through the air inlet channel, heat is transmitted to materials through the material guide plate, and then water in the materials is vaporized and separated; and meanwhile, the material guide plate is spiral, the material falling time is prolonged, the material drying time is prolonged, airflow does not make contact with the materials, the dust raising phenomenon caused by hot airflow is avoided, the dust raising phenomenon caused by drying airflow is avoided, and meanwhile hot airflow circulation automatic temperature control is achieved, and energy consumption is reduced.
(71) Heyang Yunhui New Building Mat Co Ltd (CN)
