ABB introduces gearless conveyor drive for wider range of motors

On 06.02.2018, ABB announced that its innovative gearless conveyor drive is available for use on a wider range of conveyor systems. Already proven on larger motors, the newest drive is designed for medium power range motors (1 to 3 MW per motor) to make this technology economically feasible for a broader range of conveyor systems, including the use on mobile equipment in mining operations. The new solution can be applied for both greenfield and brownfield systems, and significantly decreases the cost threshold for gearless conveyor technology.

Fewer parts and new motor technology increase the reliability and efficiency of the overall conveyor system. A permanent magnet motor specifically designed for mining applications is a core element of this system that contributes to its reliability and ability to perform in the most challenging environments.

The gearless conveyor drive system eliminates the gearbox from the drive. This reduces the number of main wear parts, so less maintenance is needed, and lengthens the lifespan of the equipment. The expected lifespan for the drive train increases by more than 10 years when compared to traditional geared systems, to a projected in service life of 25 years.

Other advantages include a considerable reduction in the drive system’s footprint, so it can be installed in smaller spaces, less weight, and a reduction in the instrumentation required to operate the system. The gearless drive design is also more energy efficient, requiring less power, and operates more quietly, thus reducing noise emissions.

In July 2017, the pilot project of this solution was installed in collaboration with Lausitz Energie Bergbau AG (LEAG) in the open-pit lignite mine Jänschwalde, located close to Cottbus/Germany. The new gearless solution was installed on a high capacity (15000 t/h) discharge conveyor of a bucket chain excavator in parallel with the existing geared drive. Both drives connect to the same pulley shaft to allow for exact benchmarking. The gearless solution has performed better in regard to dynamic accuracy and overall efficiency than the existing traditional solution.

The operational data demonstrate the advantages of the gearless solution with less components. A gearless solution is more reliable (with a 50 % lower failure rate) and requires less maintenance. It is meeting eco design and energy performance requirements according to international standards to support the mine site’s environmental approvals or certification. The new drive also consumes 5 % less energy than the other installed drive.
