Double-kiln lime powder pneumatic conveying device
(22) 08.11.2024
(43) 20.12.2024
(57) The invention discloses a double-kiln lime powder pneumatic conveying device, and relates to the technical field of double-kiln lime powder conveying devices. The double-kiln lime powder pneumatic conveying device comprises a main body mechanism, the main body mechanism comprises a draught fan, a first pipeline and a second pipeline, and the output end of the draught fan is fixedly communicated with the first pipeline; the first pipeline and the second pipeline are fixedly communicated through a flange, the surface of the first pipeline is fixedly sleeved with a first half box, the surface of the second pipeline is sleeved with a second half box, the first half box and the second half box are fixedly connected through bolts, and air leakage detection mechanisms are arranged on the surfaces of the first pipeline and the second pipeline. According to the double-kiln lime powder pneumatic conveying device, the whistle unit, the visual warning unit and the leaking stoppage unit are used in cooperation, the attention of maintenance personnel is attracted, the maintenance personnel can conveniently find the gas leakage condition in time, and therefore continuous loss and waste of pneumatic force are avoided, and the conveying efficiency of lime powder is improved.
(71) Jiangsu Longjing Machinery and Equipment Co. Ltd., (CN)
