US 2021/0198142 A1

Oxyfuel clinker production with special oxygen addition

(22) 26.04.2019

(43) 01.07.2021

(57) Processes and plants for producing cement clinker, in which an oxygen-containing gas having a proportion of 15% by volume or less of nitrogen and a proportion of 50% by volume or more of oxygen is conveyed from a first section of the cooler directly adjoining the top of the furnace into the rotary furnace and is optionally additionally conveyed to the calciner, and where the total gas streams fed in to the combustion processes consist to an extent of more than 50% by volume (preferably more than 85% by volume) of oxygen.

(71) thyssenkrupp Industrial Solutions AG, Essen (DE)

(73) thyssenkrupp Intellectual Property GmbH, Essen (DE)

x

Related articles:

Issue 2020-1-2 WO 2019/211202 A1

Oxyfuel clinker production with special oxygen addition

(22) 26.04.2019 (43) 07.11.2019 (57) Methods and systems for the production of cement clinker, wherein an oxygen-containing gas, which has a proportion of 15 vol.% or less of nitrogen and a proportion...

more
Issue 2021-6 WO 2021/001781 A1

Clinker

(22) 02.07.2020 (43) 07.01.2021 (57) The present invention relates to clinker, in particular cement clinker. The invention provides a method of preparing clinker and extends to clinker prepared in...

more
Issue 2021-4 CZ34936 (U1)

Low-energy clinker for producing cement with increased initial strength

(22) 02.12.2020 (43) 23.03.2021 (57) 1. Cement clinker, consisting of the following components: alite, belite, tricalcium aluminate, tetracalcium aluminate ferrite and free lime, characterized in that...

more
Issue 2021-6 WO 2021/124261 A1

Method of producing cement clinker and a second calcined material

(22) 18.12.2020 (43) 24.06.2021 (57) A method of producing cement clinker and a second calcined material, wherein the cement clinker is produced in a first production line and the second calcined...

more
Issue 2020-1-2 WO 2019/211196 A1

Oxyfuel clinker production without recirculation of the preheater exhaust gases

(22) 26.04.2019 (43) 07.11.2019 (57) The invention relates to methods and installations for producing cement clinker without recirculation of the preheater exhaust gases, wherein, in said preheater,...

more
