A method and apparatus for reduction of HCI emission
from cement plants using cement raw meal as absorber
(22) 29.08.2019
(43) 05.03.2020
(57) The invention relates to a method for reduction of HC1 emission from a cement plant based on a treatment of a preheater (1) and/or bypass gas stream, characterized in that a cement raw meal, as a HC1 absorber, is dispersed in the gas stream(s) from which HC1 is to be removed; the cement raw meal is introduced from a raw mill (6) and/or a silo (8) into a pipe with a up going gas flow; the pipe being arranged in fluid communication at a point after a gas conditioning tower (7) and/or before a particle filter unit (5) and/ or in a by-pass line before particle filter (4).
(71) FLSmidth A/S, Vigerslev Alle 77, 2500 Valby (DK)
(84) ARIPO (BW, GH, GM, KE, LR, LS, MW, MZ, NA, RW, SD, SL, ST, SZ, TZ, UG, ZM, ZW), Eurasian (AM, AZ, BY, KG, KZ, RU, TJ, TM), European (AL, AT, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GB, GR, HR, HU, 1E, IS, IT, LT, LU, LV, MC, MK, MT, NL, NO, PL, PT, RO, RS, SE, SI, SK, SM, TR), OAPI (BF, BJ, CF, CG, CI, CM, GA, GN, GQ, GW, KM, ML, MR, NE, SN, TD, TG)
